Displaying Node Properties
You display Node properties through the Node Properties dialog box. You can use
any of the following methods to open the Node Properties dialog box:
■ Double-click a row in the Node List View or right-click a row and choose
Node Properties from the menu.
■ Right-click a port in the Port Card View.
■ Right-click a port’s row in the Port List View.
■ Right-click a port’s bar graph in the Performance View and choose Node
Properties from the menu that displays.
■ Click a port, port row, or bar graph in the views listed above and then click
Product > Port > Node Properties.
Note: If a node is not logged in, a message displays indicating that node information
is not available.
Figure 28: Node Properties dialog box
■ Port Number—The physical port number on the director to which the node is
connected.
■ Fibre Channel Address—In Open Systems style only, this displays the
three-byte Fibre Channel Address of the node.
