HP StorageWorks B-series Data Center Fabric Manager Enterprise, Professional Plus, and Professional 10.3.4 Release Notes (5697-0436, April 2010 - includes all 10.3.x versions)

SolutionClosed defect summary
Fixed in DCFM 10.3.0
nl
Workaround prior to this version:
nl
Use the FOS-based switch as the seed
switch.
When an M-EOS-based switch is used as a seed switch and is attached
to an FOS-based switch, the connected end devices are not accurately
displayed in the Topology. The device attached to the FOS-based
switch is shown without any connection, and the device attached to
the M-EOS-based switch is not shown at all.
Fixed in DCFM 10.3.0
nl
Workaround prior to this version:
nl
Delete and then rediscover the fabric.
M-EOS Element Manager cannot be launched after editing the SNMP
values from the Discovery Setup dialog.
Fixed in DCFM 10.3.0
The FCIP tunnel between two HP StorageWorks 400 MP Routers does
not appear in the Topology.
Fixed in DCFM 10.3.0
When monitoring performance, the I/O flow does not appear for some
switches or for GbE ports with one FCIP tunnel.
Fixed in DCFM 10.3.0
The Connected Device Property information is not updated when a
CNA connected to HP StorageWorks 2408 FCoE Converged Network
Switch is down in the Virtual FCoE Ports tab. The Connected Device
Property value displays 1 instead of 0.
Fixed in DCFM 10.3.0
Unable to download firmware using an external FTP as external FTP
server, and SCP server options are not available in the Firmware
Management dialog if an external FTP server is selected.
Fixed in DCFM 10.3.0
If the HP StorageWorks 2408 FCoE Converged Network Switch is
selected from the Connectivity Map, the Product Tree toggles or flickers.
Fixed in DCFM 10.3.0
You cannot activate zone config while bad zone config is dis-
played.
Fixed in DCFM 10.3.0
During historical data collection, event logs can grow to several GBs
in size and fill the hard drive.
Fixed in DCFM 10.3.0
When IFLs are removed from back-to-edge routing, the Topology occa-
sionally appears blank and causes a NULL pointer exception in the
Client log.
Fixed in DCFM 10.3.0Access Gateway-based logins are displayed incorrectly in DCFM.
Fixed in DCFM 10.3.0
The right-click menu of unoccupied ports in M-EOS-based switches lists
CGWL options instead of the correct options.
Fixed in DCFM 10.3.0
The local client displays the Master Log correctly, but remote clients
display a blank Master Log.
Fixed in DCFM 10.3.0
HP StorageWorks Edge Switch 2/12 running firmware 9.9.x is missing
from the Topology after migration from EFCM to DCFM; it must be
rediscovered to appear.
Fixed in DCFM 10.3.0
The Port Picker dialog shows an incorrect port count when switches
without an EGM license are selected.
nl
NOTE:
nl
All HP switches have this license by default.
Fixed in DCFM 10.3.0
Discovery status is inconsistent for VF switches in the fabric when a
non-VF switch is discovered as the seed switch.
B-series Data Center Fabric Manager Enterprise, Professional Plus, and Professional 29
