HP StorageWorks B-series Data Center Fabric Manager Enterprise, Professional Plus, and Professional 10.3.4 Release Notes (5697-0436, April 2010 - includes all 10.3.x versions)

SolutionClosed defect summary
Fixed in DCFM 10.3.0
The I/O flow between the HP StorageWorks 2408 FCoE Converged
Network Switch and connected storage does not appear in the Topo-
logy, incorrectly implying that there is no traffic flow between the two
devices.
Fixed in DCFM 10.3.0
The V icon does not appear for the NPIV ports when a server port
mapping is done.
Fixed in DCFM 10.3.0
The link between a storage device or HBA and a switch does not al-
ways appear in the Topology.
Fixed in DCFM 10.3.0Backup network credentials are updated when the backup is disabled.
Fixed in DCFM 10.3.0
When Domain port, index type is selected in the Potential Members
list, the ports are not sorted properly.
Fixed in DCFM 10.3.0
nl
Workaround prior to this version:
nl
Deselect the Only events for current
view box, and then select it again to
update the display.
When Only events for current view is selected, the Master Log events
are not updated with the fabrics currently in the view.
Fixed in DCFM 10.3.0
The Chassis Group is displayed in the middle of the Device Tree. De-
pending on the sorting solution, users might not find it.
Fixed in DCFM 10.3.0
nl
Workaround prior to this version:
nl
Restart Services to start the services.
However, if you reopen SMC, the
status returns to Unknown.
After migrating from EFCM to DCFM, Server Management Console
(SMC) lists all Services Status other than for Database Server as Un-
known.
Fixed in DCFM 10.3.0
A user with performance set to No Privilege can launch the Histor-
ical Graph, Historical Report, and Real Time Graph in the Port Property
dialog.
Fixed in DCFM 10.3.0
nl
Workaround prior to this version:
nl
Reduce the load on the server and
generate a new Real Time Graph.
When a server is busy, users cannot view the Real Time Graph and
the Error receiving real time statistics. Server did
not respond and poll was skipped message is displayed in
the Master Log.
Fixed in DCFM 10.3.0Users cannot launch WebTools from DCFM.
Fixed in DCFM 10.3.0
nl
Workaround prior to this version:
nl
Manually add the TI zone members
from LHS to the TI zone in RHS.
In the Compare Merge dialog, the TI zone from LHS is not added to
the zone node in RHS, and an error is displayed.
Fixed in DCFM 10.3.0
In the Server Management Console (SMC), clicking Refresh does not
refresh the window.
Fixed in DCFM 10.3.0The Logical Switch dialog displays only GE0, even if GE1 also exists.
Fixed in DCFM 10.3.0
If you select Configure > Names, a chassis continues to be displayed
after you unmonitor the fabric containing the chassis.
Fixed in DCFM 10.3.0
In the Logical Switch dialog, clicking the right arrow to move or find
a GbE port does nothing.
34
