HP StorageWorks B-series Data Center Fabric Manager Enterprise, Professional Plus, and Professional 10.3.4 Release Notes (5697-0436, April 2010 - includes all 10.3.x versions)
Table Of Contents
- B-series Data Center Fabric Manager Enterprise, Professional Plus, and Professional
- Version
- Description
- New hardware platforms
- New software features
- Enhancements
- Supported switches and firmware
- Supported operating systems
- Supported feature summary for DCFM
- Important notes
- Installation instructions
- Documentation updates
- DCFM 10.3.0 fixes
- DCFM 10.3.1 fixes
- DCFM 10.3.2 fixes
- DCFM 10.3.3 fixes
- DCFM 10.3.4 fixes
- Effective date
Supported switches and firmware
Table 1 lists switches and firmware families supported with this release. This does not imply that all
firmware versions listed in the left column are still supported by HP, but rather that those are the
firmware streams on which the corresponding switches are, or were, supported. It also does not imply
that all the firmware listed streams are supported on each of the corresponding switches. HP
recommends using the latest software versions to get the greatest benefit from the SAN.
Table 1 Supported switches and firmware
Switch/DirectorSwitch firmware
HP StorageWorks SAN Switch 2/32 (Brocade 3900)
HP StorageWorks SAN Switch 2/8V (Brocade 3250)
HP StorageWorks SAN Switch 2/16V (Brocade 3850)
HP StorageWorks SAN Switch 4/32 (Brocade 4100)
HP StorageWorks 400 Multi-Protocol Router (Brocade 7500)
1
HP StorageWorks 4/8, 4/16 SAN Switch (Brocade 200E)
HP StorageWorks SAN Switch 4/64 (Brocade 4900)
2
HP StorageWorks SAN Switch 4/32B (Brocade 5000)
3
HP StorageWorks 8/8, 8/24 SAN Switch (Brocade 300)
4
HP StorageWorks 8/40 SAN Switch (Brocade 5100)
4
HP StorageWorks 8/80 SAN Switch (Brocade 5300)
4
HP StorageWorks Core Switch 2/64 (Brocade 12000)
HP StorageWorks SAN Director 2/128 (Brocade 24000)
HP StorageWorks 4/256 SAN Director (Brocade 48000)
• HP StorageWorks 4/256 SAN Director 16 Port 4Gb Blade (FC4-16)
• HP StorageWorks 4/256 SAN Director 32 Port 4Gb Blade (FC4-32)
•
HP StorageWorks 4/256 SAN Director 48 Port 4Gb Blade (FC4-48)
2
•
HP StorageWorks iSCSI Director Blade (FC4-16IP)
2
•
HP StorageWorks Multi-Protocol Router Blade (FR4-18i)
1
•
HP StorageWorks SAN Director 6 Port 10Gb FC ISL Blade (FC10-6)
5
HP StorageWorks DC SAN Backbone Director (Brocade DCX)
6
• HP StorageWorks DC SAN Director 16 Port 8Gb FC Blade (FC8-16)
• HP StorageWorks DC SAN Director 32 Port 8Gb FC Blade (FC8-32)
• HP StorageWorks DC SAN Director 48 Port 8Gb FC Blade (FC8-48)
• HP StorageWorks Multi-Protocol Router Blade (FR4-18i)
• HP StorageWorks DC SAN Director 6 Port 10Gb FC ISL Blade (FC10-6)
• HP DC Switch Encryption FC Blade
• HP StorageWorks DC SAN Director Multiprotocol Extension Blade (Brocade FX8-
24)
7
• HP StorageWorks DC SAN Director Switch 10/24 FCoE Blade (Brocade FCOE10-
24)
7
FOS 5.0.x, 5.1.x,
5.2.x, 5.3.x, 6.0.x,
6.1.x, 6.2.x, and
6.3.x
8
