Installation Tasks
a. Select the appropriate time zone from the drop-down list at
the top of the dialog box.
b. If instructed by the customer’s system administrator, select the
Automatically adjust clock for daylight saving changes check box.
c. Click Apply. Record time zone and daylight savings
information for reference if the EFC server hard drive fails and
must be restored.
5. At the Date/Time Properties dialog box, click the Date & Time tab.
The dialog box displays with the Date & Time page open.
6. To change the date and time:
a. Select the month from the drop-down list under Date.
b. Click the up or down arrow adjacent to the year field and
select the year.
c. Click the day on the calendar to select the date.
d. Click in the time field and enter the time.
e. Click the up or down arrow adjacent to the time field and
select AM or PM.
f. Click Apply.
7. Click OK to close the Date/Time Properties dialog box.
8. Click close (X) at the upper right corner of the Control Panel
window to close the window and return to the Windows 2000
desktop.
Task 11: Configure the Call-Home Feature (Optional)
The management server has an optional call-home feature that
provides automatic dial-out through the internal modem to a service
support facility to report switch problems. The problem is logged into
the support facility’s tracking system for resolution. To configure the
call-home feature:
1. There are two jacks on the management server’s internal modem:
one for the call-home connection (LINE), and the other for a
telephone (PHONE). Ensure a telephone cable is routed and
connected to the LINE jack at the rear of the management server
(connected while performing Task 7: Configure Management Server
Password and Network Addresses on page 2-25).
