FW 08.01.00 McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual (620-000155-220, November 2005)

2
Task 14: Record or Verify Management Server Restore Information
2-53
Installation Tasks
Task 14: Record or Verify Management Server Restore
Information
Configuration information must be recorded to restore the
management server in case of hard drive failure. Refer to Appendix
C, Restore EFC Server for instructions. To record or verify
management server configuration information:
1. Verify network configuration information is recorded. The
information was recorded while performing Task 7: Configure
Management Server Password and Network Addresses on page 2-25
and Task 8: Configure Management Server Information on page 2-30.
a. Verify the default LCD panel password (9999) or changed
password is recorded.
b. Verify default or changed network addresses are recorded for
the private LAN connection (LAN 2):
• IP address - default is 10.1.1.1.
• Subnet mask - default is 255.0.0.0.
• Gateway address - default is blank.
• DNS server IP address - default is blank.
c. Verify default or changed network addresses are recorded for
the public LAN connection (LAN 1):
• IP address - default is 192.168.0.1.
• Subnet mask - default is 255.0.0.0.
• Gateway address - default is blank.
• DNS server IP address - default is blank.
d. Verify the default computer name (EFCSERVER) or changed
computer name is recorded.
2. Verify user passwords and other information are recorded. The
information was recorded while performing Task 9: Configure
Windows 2000 Users on page 2-38.
3. Verify date and time information is recorded. The information
was recorded while performing Task 10: Set Management Server
Date and Time on page 2-44.
a. Verify the time zone is recorded.
