McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Installation Tasks
• WWNs of switches connected to E_Ports (E_Port connection
policy). The WWN is the WWN of the attached switch.
• WWNs of devices connected to F_Ports and switches connected
to E_Ports (all-ports connection policy).
Notes
• When the Switch Binding feature is first installed and has not
been enabled, the Switch Membership List is empty. When you
enable Switch Binding, the Membership List is populated with
WWNs of devices, switches, or both that are currently connected
to the switch.
• If the switch is offline and you activate switch binding, the
Membership List is not automatically populated.
• Edits to the Switch Binding Membership list will be maintained
when you enable or disable Switch Binding.
After enabling Switch Binding, you prohibit devices and/or switches
from connecting with switch ports by removing them from the
Membership List in the Switch Binding Membership List dialog box.
You allow connections by adding them to the Membership List. You
can also add detached nodes and switches as well.
Enable/Disable Switch Binding
1. Select the State Change option from the Configure menu's Switch
Binding submenu. The Switch Binding State Change dialog box
displays.
Figure 2-61 Switch Binding State Change Dialog Box
2. Perform one of the following steps:
