McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Installation Tasks
NOTE: Do not simultaneously press the Ctrl, Alt, and Delete keys.
This action logs the user on to the browser-capable PC, not the
rack-mount management server.
f. Type the default Windows 2000 user name and password and
click OK. The management server’s Windows 2000 desktop
opens and the SAN management Login dialog box displays.
NOTE: The default Windows 2000 user name is Administrator and
the default password is password. The user name and password are
case-sensitive.
g. Type the SAN management default user name and password
and select an management server from the management server
drop-down list.
NOTE: The default SAN management user name is Administrator
and the default password is password. The user name and password
are case-sensitive.
h. Click Login. The SAN management application opens and the
Products View appears.
6. Remove the base EfcData restore CD from the CD-RW drive and
store the CD in a safe location. Insert a blank rewritable CD into
the CD-RW drive and format the CD. Refer to step 1 of this
procedure for formatting instructions.
Task 25: Configure the Switch from the EFCM Basic Interface
(Optional)
Perform these procedures to configure the product from the EFCM
Basic Edition interface. A browser-capable PC with Internet or
Ethernet LAN access is required. To open the interface:
1. Connect the Ethernet patch cable (supplied with the product) to
the RJ-45 connector (labelled 10/100) at the front panel.
2. Connect the remaining end of the Ethernet cable to the Internet or
LAN segment as directed by the customer. If the hub installed in
Task 2: Unpack, Inspect, and Install the Ethernet Hub (Optional)
provides connectivity, connect the cable to any available hub port.
