McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Installation Tasks
4. Route a multimode or singlemode fiber-optic cable (depending
on the type of SFP transceiver installed) from a
customer-specified E_Port of the switch to the director.
5. Connect the switch-attached fiber-optic cable to the port SFP
transceiver.
6. If the switch is managed by an attached management server, go to
step 7. If the switch is managed by the EFCM Basic Edition
interface:
a. At the Configure panel, select View at the left side of the panel.
The View panel opens with the Unit page displayed.
b. At the View panel, click the Port Properties tab. The Port
Properties page displays with a port number selected
(highlighted red), and port information listed.
c. Ensure the Operational State field displays Online and the
Reason field displays N/A or is blank. If an ISL segmentation or
other problem is indicated, go to MAP 0000: Start MAP on
page 3-6 to isolate the problem. If no problems are indicated,
installation tasks are complete.
7. At the management server’s Product View, click the switch icon.
The Hardware View for the selected switch displays.
8. Click the port connector (leftmost port) to open the Port Properties
dialog box.
