McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
203 Power supply ac voltage recovery. No action required.
204 Power supply DC voltage recovery. No action required.
206 Power supply removed. Replace FRU.
207 Power supply installed. No action required.
208 Power supply false shutdown. Go to MAP 0100.
300 First cooling fan failed. Go to MAP 0500.
301 Second cooling fan failed. Go to MAP 0500.
301 Third cooling fan failed. Go to MAP 0500.
303 Fourth cooling fan failed. Go to MAP 0500.
310 First cooling fan recovered. No action required.
311 Second cooling fan recovered. No action required.
312 Third cooling fan recovered. No action required.
313 Fourth cooling fan recovered. No action required.
400 Power-up diagnostic failure. Go to MAP 0200.
410 CTP card reset. No action required.
411 Firmware fault occurred. Go to MAP 0200.
421 Firmware download complete. No action required.
423 CTP firmware download initiated. No action required.
430 Excessive Ethernet transmit errors. Go to MAP 0400.
431 Excessive Ethernet receive errors. Go to MAP 0400.
432 Ethernet adapter reset. Go to MAP 0400.
433 Non-recoverable Ethernet fault. Go to MAP 0400.
440 Embedded port hardware failure. Go to MAP 0600.
442 Port module anomaly detected. No action required.
504 Port module failure - error threshold exceeded. Go to MAP 0600.
Table 3-3 Event Codes versus Maintenance Action (continued)
Event
Code
Explanation Action
