MAP 0000: Start MAP
3-15
Diagnostics
20
Port beaconing is enabled.
a. Consult with the customer and next level of support to determine
the reason port beaconing is enabled.
b. Disable port beaconing:
1. At the Hardware View, right-click the port graphic. A pop-up
menu appears.
2. Click Enable Beaconing. The check mark disappears from
the box adjacent to the option, and port beaconing is
disabled.
Was port beaconing enabled because port failure or degradation was
suspected?
YES NO
↓ The switch appears operational.
Go to step 2.
21
At the Port Properties dialog box, does the Operational State field
display a Segmented E_Port message?
NO YES
↓ E_Port segmentation is indicated. Go to step 23 to obtain
event codes. If no event codes are found, go to MAP 0700:
Fabric, ISL, and Segmented Port Problem Determination on
page 3-91.
A message displays indicating a link incident or port problem. Go to
step 23 to obtain event codes. If no event codes are found, go to MAP
0600: Port Failure and Link Incident Analysis on page 3-71.
22
A link incident may have occurred, but the LIN alerts option is not
enabled for the port and the attention indicator does not appear.
At the Hardware View, select Link Incident Log from the Logs menu
on the navigation control panel. The Link Incident Log displays.
