3
3-22
McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
• The switch-to-PC Internet link could not be established.
• AC power distribution in the switch failed, or AC power was
disconnected.
• The switch’s CTP card failed.
Continue.
41
Ensure the switch reporting the problem is connected to facility AC
power. Inspect the switch for indications of being powered on, such
as:
• At the front panel, an illuminated PWR LED or ERR LED.
• Green LEDs illuminated on the power supplies.
• Audio emanations and airflow from fans.
Does the switch appear powered on?
YES NO
↓ A power distribution problem is indicated. Go to MAP 0100:
Power Distribution Analysis on page 3-27.
42
At the front of the switch, inspect the amber ERR LED.
Is the LED illuminated?
NOYES
↓ A FRU failure or link incident is indicated. Go to step 52 to
obtain event codes that identify the failure. Exit MAP.
43
Either a switch-to-PC Internet link problem (Internet too busy or IP
address typed incorrectly) or a CTP card failure is indicated.
a. Wait approximately five minutes, then attempt to login to the
switch again.
b. At the Netsite field (Netscape Navigator) or Address field
(Internet Explorer), type http://xxx.xxx.xxx.xxx, where
xxx.xxx.xxx.xxx is the IP address of the switch (obtained in step
1). The Username and Password Required dialog box appears.
