McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
Is a link incident or port problem indicated for any of the ports?
NO YES
↓ A link incident problem or port SFP failure is indicated. Go to
step 52 to obtain event codes. If no event codes are found,
go to MAP 0600: Port Failure and Link Incident Analysis on
page 3-71.
50
Inspect the power supply operational states.
a. At the View panel, click the Component Properties tab. The View
panel (Component Properties tab) displays.
b. Inspect the State fields for both power supplies.
Does the State field display a Failed message for either power
supply?
NO YES
↓ A power supply failure is indicated. Go to step 52 to obtain event
codes. If no event codes are found, go to MAP 0100: Power
Distribution Analysis on page 3-27.
51
Inspect the State fields for Fan 0, and Fan 1 through Fan 3.
Does the State field display a Failed or Not Installed message for
any of the fans?
YES NO
↓ The switch appears operational.
A fan failure is indicated. Continue to the next step to obtain event
codes. If no event codes are found, go to MAP 0500: Fan and CTP
Card Failure Analysis on page 3-66.
52
Obtain event codes from the EFCM Basic Edition event log.
If multiple event codes are found, note all codes and associated severity
levels. Record the date, time, and listed sequence, and determine if the
codes are related to the reported problem. Begin fault isolation with the
most recent event code with the highest severity level. Other codes may
accompany this event code, or may indicate a normal indication after a
problem is recovered.
