McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
1
Was an event code 200, 201, 202, or 208 observed at the Sphereon
3032/3232 Event Log (EFC Server) or at the EFCM Basic Edition
event log?
YES NO
↓ Go to step 3.
2
The following table lists event codes, brief explanations of the codes,
and the associated steps that describe fault isolation procedures.
3
Is remote fault isolation being performed at the EFC Server?
YES NO
↓ Remote fault isolation is being performed through the EFCM
Basic Edition interface. Go to step 20.
4
Does inspection of a power supply indicate a failure (green LED
extinguished)?
NO YES
↓ Go to step 6.
5
Does a blinking red and yellow diamond (failed FRU indicator) appear
to overlay a power supply graphic at the EFC Server Hardware View?
YES NO
↓ Go to step 11.
Event
Code
Explanation Action
200 Power supply AC voltage failure. Go to step 6.
201 Power supply DC voltage failure. Go to step 10.
202 Power supply thermal failure. Go to step 10.
208 Power supply false shutdown. Go to step 6.
