Diagnostics
b. At the Hardware View, observe the graphic representing the
power supply and ensure a failure symbol (blinking red and
yellow diamond) does not appear.
Is a failure indicated?
YES NO
↓ The switch appears operational.
10
A redundant power supply failed and must be removed and replaced.
(RRP: Power Supply on page 5-4).
• This procedure is concurrent and can be performed while the
switch is powered on.
• Perform the data collection procedure after FRU removal and
replacement.
Did power supply replacement solve the problem?
NO YES
↓ The switch appears operational.
Contact the next level of support.
11
At the Product View, does a grey square appear at the alert panel and
as the background to the icon representing the switch reporting the
problem?
The grey square indicates the EFC Server cannot communicate with
the switch because:
• The switch-to-EFC Server Ethernet link failed.
• AC power distribution in the switch failed, or AC power was
disconnected.
• The switch’s CTP card failed.
YES NO
↓ The switch appears operational.
12
Ensure the power switch is set to the Power On (1) position. Inspect
the switch for indications of being powered on, such as:
• At the front panel, an illuminated PWR or ERR indicator.
