McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
YES NO
↓ Go to step 17.
16
Verify operation of both power supplies.
a. Inspect the power supplies and ensure the green LEDs
illuminate.
b. At the Hardware View, observe the graphics representing the
power supplies and ensure a failure symbol (blinking red and
yellow diamond) does not appear.
Is a failure indicated?
YES NO
↓ The switch appears operational.
17
Inspect the switch for indications the power supplies are operational,
but the switch is not receiving DC power. Indications include:
• Green LEDs illuminated on one or both power supplies.
• PWR and ERR LEDS extinguished at the switch front panel.
• All green and amber port LEDs extinguished.
Does the switch appear powered off while the power supplies appear
operational (one or both power supply LEDs illuminated)?
NO YES
↓ Go to step 19.
18
Both power supplies failed and must be removed and replaced (RRP:
Power Supply on page 5-4). Perform the data collection procedure
after FRU removal and replacement.
Did replacement of both power supplies solve the problem?
NO YES
↓ The switch appears operational.
Contact the next level of support.
