MAP 0100: Power Distribution Analysis
3-33
Diagnostics
19
One or both power supplies appear operational, but the CTP card is
not receiving DC power. An in-card circuit breaker may have tripped
due to a power surge or the CTP card failed.
Reset the switch (Reset the Switch on page 4-42).
Did a switch reset solve the problem?
NO YES
↓ The switch appears operational.
A CTP card failure is indicated. Because the CTP card is not a FRU,
replace the switch
20
Does the EFCM Basic Edition interface appear operational?
NO YES
↓ Go to step 22.
21
A Page cannot be found, Unable to locate the server, HTTP 404 -
file not found, or other similar message appears. The message
indicates the web browser PC cannot communicate with the switch
because:
• The switch-to-PC Internet (Ethernet) link could not be
established.
• AC power distribution in the switch failed, or AC power was
disconnected.
• The switch CTP card failed.
Go to step 12.
22
Inspect the power supply operational states at the EFCM Basic
Edition interface.
a. At the View panel, click the Component Properties tab. The View
panel (Component Properties tab) displays.
b. Inspect the State fields for Power Supply 0 and Power Supply
1.
Does the State field display a Failed or Not Installed message for
either power supply?
