McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
NO YES
↓ A redundant power supply failure is indicated. Go to step 6.
The switch appears operational.
MAP 0200: POST, Reset, or IPL Failure Analysis
When the switch is powered on, it performs a series of power-on
self-tests (POSTs). When POSTs complete, the switch performs an
initial program load (IPL) that loads firmware and brings the unit
online. This MAP describes fault isolation for problems that may
occur during the POST/IPL process.
If an error is detected, the POST/IPL process continues in an attempt
to initialize the switch and bring it online. But an event code 400
displays when the switch completes the POST/IPL process.
1
Was an event code 400 or 411 observed at the Sphereon 3032/3232
Event Log (EFC Server) or at the EFCM Basic Edition event log?
YES NO
↓ Analysis for the failure is not described in this MAP. Go to
MAP 0000: Start MAP on page 3-6.
2
The following table lists event codes, brief explanations of the codes,
and the associated steps that describe fault isolation procedures.
3
POST/IPL diagnostics detected a CTP card failure as indicated by an
event code 400 with supplementary bytes of event data.
• Byte 0 is a FRU code (02) that indicates a failed CTP card.
• Byte 1 is the slot number (00) for the CTP card.
Event
Code
Explanation Action
400 Power-up diagnostic failure. Go to step 3.
411 Firmware fault occurred. Go to step 4.
