3
MAP 0400: Loss of Console Communication
3-47
Diagnostics
3
Did the switch-to-EFC Server Ethernet connection recover?
NO YES
↓ The switch-to-EFC Server connection is restored and
appears operational.
Contact the next level of support.
4
Reboot the EFC Server PC.
a. Click the Windows Start button. The Windows 2000 Workstation
menu displays.
b. At the Windows 2000 Workstation menu, select Shut Down. The
Shut Down Windows dialog box appears.
c. At the Shut Down Windows dialog box, select Shut down the
Computer and click Ye s to power off the PC.
d. Wait approximately 30 seconds and power on the PC. After
POSTs complete, the Begin Logon dialog box displays.
e. Simultaneously press Ctrl, Alt, and Delete to display the Logon
Information dialog box. Type a user name and password
(obtained in MAP 0000: Start MAP on page 3-6) and click OK.
The EMS and EFC Manager applications start and the EFC
Manager Login dialog box displays.
f. At the EFC Manager Login dialog box, type a user name,
password, and EFC Server name (obtained in MAP 0000: Start
MAP on page 3-6), and click Login. The application opens and
the Product View displays.
