3
MAP 0500: Fan and CTP Card Failure Analysis
3-69
Diagnostics
6
Does the EFCM Basic Edition interface appear operational?
YES NO
↓ Analysis for an Ethernet link, AC power distribution, or CTP
card failure is not described in this MAP. Go to MAP 0000:
Start MAP on page 3-6. If this is the second time at this step,
contact the next level of support.
7
Inspect the fan operational states at the EFCM Basic Edition
interface.
a. At the View panel, click the Component Properties tab. The View
panel (Component Properties tab) displays.
b. Inspect the State fields for Fan 0 through Fan 3.
Does the State field display a Failed message for any fan?
YES NO
↓ The switch appears operational.
8
A fan failed or is improperly installed.
a. Partially remove a fan from the switch chassis.
b. Reseat the fan in the chassis.
Does the fan appear to function?
NO YES
↓ The switch appears operational.
9
A fan failed and must be removed and replaced (RRP: Cooling Fan
FRU on page 5-6).
Does the fan appear to function?
NO YES
↓ The switch appears operational.
Contact the next level of support.
