MAP 0600: Port Failure and Link Incident Analysis
3-73
Diagnostics
Is an amber port LED illuminated but not blinking (beaconing)?
YES NO
↓ The switch appears operational, however a link incident
or other problem may have occurred. Perform fault isolation
at the EFC Server or customer-supplied server.
Go to step 13.
6
As indicated by a message or event code 506, 512, or 514, a Fibre
Channel port failed and the SFP optical transceiver must be removed
and replaced. Refer to RRP: SFP Transceiver on page 5-2.
• This procedure is concurrent and can be performed while the
switch is powered on and operational.
• Verify location of the failed port.
• Replace the optical transceiver with a transceiver of the same
type (shortwave or longwave).
• Perform an external loopback test for the port as part of FRU
removal and replacement. Refer to Performing Port Diagnostics
on page 4-22.
Did optical transceiver replacement solve the problem?
NO YES
↓ The switch appears operational. Exit MAP.
Contact the next level of support. Exit MAP.
7
Is fault isolation being performed at the EFCM Basic Edition
interface?
YES NO
↓ Fault isolation is being performed at the EFC Server
(or customer-supplied server). Go to step 13.
8
Does the EFCM Basic Edition interface appear operational?
NO YES
↓ Go to step 11.
