3
MAP 0600: Port Failure and Link Incident Analysis
3-75
Diagnostics
12
Install an SFP optical transceiver in the port receptacle. Refer to
RRP: SFP Transceiver on page 5-2.
• This procedure is concurrent and can be performed while the
switch is powered on and operational.
• Verify location of the failed port.
• Perform an external loopback test for the port as part of FRU
removal and replacement. Refer to Performing Port Diagnostics
on page 4-22.
Exit MAP.
13
At the EFC Server, does a blinking red and yellow diamond
(failed FRU indicator) appear adjacent to a Fibre Channel port
graphic at the Hardware View?
NO YES
↓ A port failure is indicated. Go to step 6.
14
Did a Fibre Channel port fail a loopback test?
NO YES
↓ Go to step 18.
Table 3-4 Port Operational States and Actions (EFCM Basic Edition)
Operational State Action
Offline Go to step 19.
Not Operational Go to step 19.
Port Failure Go to step 6.
Testing Internal or external loopback test in process. Exit MAP.
Invalid Attachment Go to step 22.
Link Reset Go to step 33.
Not Installed Go to step 12.
