McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Diagnostics
3
Is fault isolation being performed at the EFC Server?
YES NO
↓ Fault isolation is being performed through the EFCM Basic
Edition interface. Go to step 18.
4
Does a yellow triangle (attention indicator) appear to overlay the port
graphic at the Hardware View?
YES NO
↓ The problem is transient and the switch-to-fabric device
connection appears operational.
5
Inspect the port state and LED status for the port.
Event
Code
Explanation Action
011 Login server database invalid. Go to step 7.
021 Name server database invalid. Go to step 7.
051 Management server database invalid. Go to step 7.
052 Management server internal error. Go to step 7.
061 Fabric controller database invalid. Go to step 7.
062 Maximum interswitch hop count exceeded. Go to step 8.
063 Remote switch has too many ISLs.
070 E_Port is segmented. Go to step 10.
071 Switch is isolated. Go to step 10.
072 E_Port connected to an unsupported switch. Go to step 11.
140 Congestion detected on an ISL.
142 Low BB_Credit detected on an ISL.
150 Zone merge failure.
