McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Repair Information
The log displays ISL congestion events that cause Fibre Channel
traffic to be routed through an alternate ISL. Entries reflect the traffic
re-route status at the managed switch. The log consists of the
following columns:
• Date/Time - Date and time the re-route action occurred.
• Receive Port - The switch port number (decimal) used for
receiving Fibre Channel traffic after the re-route action.
• Target Domain - The domain ID (decimal) of the target device to
which Fibre Channel traffic from the switch was rerouted.
• Old Exit Port - The switch port number (decimal) used for
transmitting Fibre Channel traffic before the re-route action.
• New Exit Port - The switch port number (decimal) used for
transmitting Fibre Channel traffic after the re-route action.
EFCM Basic Edition
Logs
To open a EFCM Basic Edition log, click the Logs tab at the Monitor
panel. The Monitor panel opens with the Logs page displayed.
The Logs tab provides links to the following logs:
• Event Log - A listing of messages generated by the product
regarding errors and events. The four levels of events indicate an
increasing level of severity, from Informational to Severe.
• Open Trunking Re-Route Log - A log of open trunking re-route
actions made by the product.
• Link Incident Log - A log of link incidents that have occurred.
Security Log - List of security incidents that have occurred.
• Audit Log - List of events tracked for auditing purposes.
• Fabric Log - List of events associated with the Fabric.
• Embedded Port Frame Log - List of cumulative events.
• All Logs - collects the information for each log into a single text
page.
NOTE: For details on the logs, review the EFCM Basic Edition User Manual.
Each log contains a link that brings the user to a page of ASCII text
that reflects the log information present on the machine at that
moment. The log displayed is a snapshot of the current log
information. Log entries are displayed in the order in which they
