occurred, with most recent entries listed first. Each log also contains a
Clear Log button that is used to clear all the entries in the log.
At the Logs page:
• Select (double-click) a log title to open and view the contents of
the associated log, or
• Select (double-click) the All Logs title to open and simultaneously
view the contents of all logs.
The Logs page provides a Clear Log button for each log. Click the
button to delete all entries for the associated log. The Logs page also
provides a Clear All Logs button. Click the button to delete all entries
in all logs.
Using Views
The EFC Manager and Product Manager provide access to a series of
views (windows) that provide information for administrators, users,
and maintenance personnel. These views are accessed through the
Hardware View, and include the:
•Port List View.
•FRU List View.
• Node List View.
• Performance View.
• Topology View.
• Zoning View.
Port List View
The Port List View (Figure 4-8) lists and provides status information
for all switch ports. The information is useful to maintenance
personnel for isolating port problems.
To open the Port List View, select Port List from the View menu on the
navigation control panel.
