Messages
A-1
A
Invisible Body Tag
This appendix lists information and error messages that appear in
pop-up message boxes at the Sphereon 3032/3232 Element Manager.
The text of each message is followed by a description and
recommended course of action.
Sphereon 3032/3232 Element Manager Messages
This section lists Sphereon 3032/3232 Element Manager information
and error messages in alphabetical order.
A
Message A preferred path already exists between this Source Port and this
Destination Domain ID. Please reconfigure the desired path.
Description For any source port, only one path may be defined to each destination
domain ID.
Action On the Add/Change Preferred Path Dialog box, change the Preferred
Path.
Message Activating this configuration will overwrite the current
configuration.
