A
Sphereon 3032/3232 Element Manager Messages
A-27
Messages
R
Message R_A_TOV must be greater than E_D_TOV.
Description R_A_TOV must be greater than E_D_TOV.
Action Change one of the values so that R_A_TOV is greater than E_D_TOV.
Message Resource is unavailable.
Description The specified operation cannot be performed because the product is
unavailable.
Action Verify that the EFC Server-to-product link is up. If the link is up, the
EFC Server may be busy. Try the operation again later.
Message Preferred Paths can not be enabled until the Domain ID is set to
Insistent. Disable Preferred Paths, then configure Switch
Parameters.
Description If the switch’s domain ID has not been set to Insistent, the user is not
allowed to activate the Preferred Path configuration with the Enable
Preferred Paths check box selected.
Action Close the Configure Preferred Paths dialog box and select the Configure
menu, then Operating Parameters, then Switch Parameters. On the
Configure Switch Parameters dialog box, select the Insistent check box.
S
Message Send firmware failed.
Description Send firmware operation has failed.
Action Retry the operation. If the condition persists, contact support
personnel.
