Event Code Tables
B-1
B
Invisible Body Tag
This appendix lists all three-digit McDATA Sphereon 3032/3232
Switch event codes and provides detailed information about each
code. Event codes are listed in numerical order and in tabular format.
An event is an occurrence (state change, problem detection, or
problem correction) that requires user attention or that should be
reported to a system administrator or service representative. An
event usually indicates an Sphereon 3032/3232 operational state
transition, but may also indicate an impending state change
(threshold violation). An event may also provide information only,
and not indicate an operational state change. Event codes are
grouped as follows:
• 000 through 199 - system events.
• 200 through 299 - power supply events.
• 300 through 399 - fan module events.
• 400 through 499 - CTP card events.
• 500 through 599 - port module events.
• 600 through 699 - SBAR module events.
• 700 through 799 - Reserved for future use.
• 800 through 899 - Thermal
Events can be recorded in the Sphereon 3016/3216 Event Logs at the
Enterprise Fabric Connectivity (EFC) Server, or at a remote
workstation if e-mail and call-home features are enabled. An event
