B
B-14
McDATA® Sphereon 3032 and 3232 Installation and Service Manual
Event Code Tables
Event Code: 120
Message: Error detected while processing system management command.
Severity: Informational
Explanation: This event occurrs when the switch receives a command from the management tool (EFCM) that does not meet
specified boundary conditions. This may occurr as a result of a network communication error. The switch rejects
the command, then disconnects from the management tool to force error recovery processing. The management
tool should immediately reconnect, and the operation can be retried.
Action: No actoin required if this is an isolated event. If this event is persistent, perform a data collection operation for this
switch and return the data to McDATA for analysis.
Event Data: None.
Distribution: Switch EFC Server Host
Nonvolatile
System
Event Log
System
Error
Indicator
Event Log E-Mail Call-Home Sense Info Link Incident
✔✔
Event Code: 121
Message: Zone set activation failed. Zone set too large.
Severity: Informational
Explanation: This event occurrs when the switch receives a zone set activation command from the management tool (EFCM)
that exceed the size supported by the switch. The switch rejects the command, then disconnects from the
management tool to force error recovery processing. The management tool should immediately reconnect, and
the operation can be retried.
Action: Reduce the size of the zone set so it conforms to the limits specified in the user manual and retry the activation.
Verify that the number of zones and zone members in the zone set are within the limits stated in the user manual,
or try reducing the length of zone names.
Event Data: None.
Distribution: Switch EFC Server Host
Nonvolatile
System
Event Log
System
Error
Indicator
Event Log E-Mail Call-Home Sense Info Link Incident
✔✔
