B
B-18
McDATA® Sphereon 3032 and 3232 Installation and Service Manual
Event Code Tables
Event Data for Event Code 150
Byte 0-3: Number of the port with the Zone Merge failure.
Byte 4-7: Response Code:
01 = Fabric Busy.
02 = Failed. Expected response code for a zone
merge failure.
03 - EF = Reserved
F0 - FF = Vendor Unique.
Byte 8 - 11: Reason Code:
00 = No reason code
01 = Invalid Data Length. Logical error with the
zone merge frame.
02 = Unsupported Command
03 = Reserved
04 = Not Authorized
05 = Invalid Request
06 = Fabric Changing
07 = Update not Staged
08 = Invalid Zone Set Format. Logical error with
the zone merge frame. See Error Codes.
09 = Invalid Data. See Error Codes.
0A = Cannot Merge. See Error Codes.
0B-EF = Reserved
F0 = Retry Limit reached. Problem sending or
receiving responses to Merge Frame.
F1 = Invalid Response Length. Logical error with
the zone merge response frame.
F2 = Invalid Response Code. Logical error with
the zone merge response frame.
F3-FF = Vendor Unique
Byte 8 - 11: Error Code:
01 = Completion Fail
02 = Not Used
03 = Zone Merge Error - too many zones.
04 = Zone Merge Error - Incompatible zones.
05 = Zone Merge Error - Too long if Reason is 0A.
06 = Zone Set Definition too Long.
07 = Zone Set either too short or not authorized.
08 = Invalid Number of Zones.
09 = Zone Merge Error - Default zone states
incompatible, if Reason Code = 0A.
0A = Invalid Protocol
0B = Invalid Number of Zone Members.
0C = Invalid Flags.
0D = Invalid Zone Member Information Length.
0E = Invalid Zone Member Information Format.
0F = Invalid Zone Member Information Port.
10 = Invalid Zone Set Name Length.
11 = Invalid Zone Name Length.
12-36 = Not used.
37 = Invalid Zone Name.
38 = Not Used.
39 = Duplicate Zone.
3A = Not Used.
3B = Not Used.
3C = Invalid Number of Zone Members.
3D = Invalid Member Type.
3E = Invalid Zone Set Name.
3F-44 = Not Used.
45 = Duplicate Member in Zone.
46-49 = Not Used.
4A = Invlaid Number of Zones.
4B = Invalid Zone Set Size.
4C = Maximum Number of Unique Zone Members
Exceeded.
4C-FF = Not Used.
