Event Code Tables
Fan Module Events (300 through 399)
Event Code: 300
Message: First cooling fan propeller has failed
Severity: Major
Explanation: Indicates that a fan is no longer operational. The fan has stopped or was removed. The remainder of the fans in
the system are installed and operational. If present, the LED on the associated fan module is turned off. The fan
has either stopped or was removed.
Action: Replace the fan module.
Event Data: Byte 0 = Failed fan number (1-6)
Distribution: Switch EFC Server Host
Nonvolatile
System
Event Log
System
Error
Indicator
Event Log E-Mail Call-Home Sense Info Link Incident
✔✔✔✔✔✔
Event Code: 301
Message: Second cooling fan propeller has failed
Severity: Major
Explanation: A second fan has failed. The fan has stopped or was removed. The remainder of the fans in the system are
installed and operational. The LED on the associated fan module is turned off. The fan has either stopped or was
removed.
Action: Replace the fan module immediately.
Event Data: Byte 0 = Failing fan number (1-6).
Distribution: Switch EFC Server Host
Nonvolatile
System
Event Log
System
Error
Indicator
Event Log E-Mail Call-Home Sense Info Link Incident
✔✔✔✔✔✔
