B
Port Module Events (500 through 599)
B-47
Event Code Tables
0x18 User port internal frame error – long frame HA Error Callouts (Words 2 & 4)
0x19 User port internal frame error – short frame HA Error Callouts (Words 2 & 4)
0x1A User port internal parity error HA Error Callouts (Words 2 & 4)
0x1B Buffer error HA Error Callouts (Words 2 & 4)
0x1C User port detected unexpected frame
transmission
HA Error Callouts (Words 2 & 4)
0x1D User port internal frame error – invalid trailer HA Error Callouts (Words 2 & 4)
0x1E User port detected frame internal integrity error HA Error Callouts (Words 2 & 4)
0x1F Internal connection time out HA Error Callouts (Words 2 & 4)
0x20 User port detected elastic store error HA Error Callouts (Words 2 & 4)
0x21 User port detected trailer parity error HA Error Callouts (Words 2 & 4)
0x22 User port detected internal frame error – long
frame
HA Error Callouts (Words 2 & 4)
0x23 Port detected SBAR response error HA Error Callouts (Words 2 & 4)
0x24 User port detected clock error HA Error Callouts (Words 2 & 4)
0x25 Port module internal address bus error HA Error Callouts (Words 2 & 4)
0x26 User module internal data bus error HA Error Callouts (Words 2 & 4)
0x27 User Port detected invalid address HA Error Callouts (Words 2 & 4)
0x28 Embedded port detected frame integrity error HA Error Callouts (Words 2 & 4)
0x29 Embedded port detected frame error – non-parity HA Error Callouts (Words 2 & 4)
0x2A Embedded port detected frame error – parity HA Error Callouts (Words 2 & 4)
0x2B Embedded port detected invalid SBAR response HA Error Callouts (Words 2 & 4)
0x2C Embedded port detected receive frame parity
error
HA Error Callouts (Words 2 & 4)
0x2D Embedded port detected connection time out HA Error Callouts (Words 2 & 4)
0x2E Embedded port detected receive fame overrun
error
HA Error Callouts (Words 2 & 4)
0x2F Embedded port detected frame transmit error HA Error Callouts (Words 2 & 4)
0x30 Embedded port detected request time out HA Error Callouts (Words 2 & 4)
