B
B-68
McDATA® Sphereon 3032 and 3232 Installation and Service Manual
Event Code Tables
0x05 SBAR module detected clock frequency error HA Error Callouts (Words 2 & 4)
0x06 Port module detected clock frequency error HA Error Callouts (Words 2 & 4)
0x07 SBAR module detected CTP interface signal
error
HA Error Callouts (Words 2 & 4)
0x08 Port module detected CTP interface signal error HA Error Callouts (Words 2 & 4)
0x09 SBAR Module detected external parity error HA Error Callouts (Words 2 & 4)
0x0A Port Module detected external parity error HA Error Callouts (Words 2 & 4)
0x0B SBAR Module detected lost of system clock HA Error Callouts (Words 2 & 4)
0x0C Port Module detected lost of system clock HA Error Callouts (Words 2 & 4)
0x0D SBAR detected invalid request from port HA Error Callouts (Words 2 & 4)
0x0E Internal SBAR time out HA Error Callouts (Words 2 & 4)
0x0F Internal SBAR parity error HA Error Callouts (Words 2 & 4)
0x10 User port internal protocol error HA Error Callouts (Words 2 & 4)
0x11 User port internal parity error HA Error Callouts (Words 2 & 4)
0x12 User port internal buffer range error HA Error Callouts (Words 2 & 4)
0x13 User port internal time out #1 HA Error Callouts (Words 2 & 4)
0x14 User port internal time out #2 HA Error Callouts (Words 2 & 4)
0x15 User port internal frame error – bad delimiter HA Error Callouts (Words 2 & 4)
0x16 User port internal frame error – CRC HA Error Callouts (Words 2 & 4)
0x17 User port internal frame error – invalid size HA Error Callouts (Words 2 & 4)
0x18 User port internal frame error – long frame HA Error Callouts (Words 2 & 4)
0x19 User port internal frame error – short frame HA Error Callouts (Words 2 & 4)
0x1A User port internal parity error HA Error Callouts (Words 2 & 4)
0x1B Buffer error HA Error Callouts (Words 2 & 4)
0x1C User port detected unexpected frame
transmission
HA Error Callouts (Words 2 & 4)
0x1D User port internal frame error – invalid trailer HA Error Callouts (Words 2 & 4)
0x1E User port detected frame internal integrity error HA Error Callouts (Words 2 & 4)
