Restore EFC Server
• EFC Management Applications CD-ROM - this CD-ROM is
shipped with the EFC Server and contains the EFC Manager,
Element Manager, and Fabric Manager applications.
• EFC Manager data directory backup on CD - the EFC Manager
data directory is automatically backed up to a removable
rewritable CD when the EFC Server is rebooted or when the data
directory contents change. The data directory includes:
— All EFC Manager configuration data (product definitions, user
names, passwords, user rights, nicknames, session options,
SNMP trap recipients, e-mail recipients, and Ethernet event
notifications).
— All log files (EFC manager logs and individual Element
Manager logs).
— Zoning library (all zone sets and zone definitions).
—Firmware library.
— Call-home settings (phone numbers and dialing options).
— Configuration data for each managed switch (stored on the
EFC Server and in NV-RAM on each switch).
• Windows 2000 configuration information - Windows 2000
network addresses, date and time information, user information,
and the product identification are recorded during installation of
the EFC Server (Task 14: Record or Verify Management Server Restore
Information on page 2-53).
Restore EFC Server Procedure
To restore the EFC Server:
1. Print the readme.txt instructions provided on the EFC Server
Restore CD-ROM.
a. Insert the EFC Server Restore CD-ROM in the CD-ROM drive
of an operational PC or laptop running the Windows 2000 4.0
operating system.
b. Click the Windows Start button. The Windows 2000 Workstation
menu displays.
c. Select Programs. The Programs menu appears.
d. Select Accessories. The Accessories menu appears.
