Glossary
g-17
Glossary
e-mail See electronic mail.
embedded web
server interface
The interface provides a graphical user interface (GUI) similar to the
Product Manager application, and supports director or switch config-
uration, statistics monitoring, and basic operations. With director or
switch firmware installed, administrators or operators with a
browser-capable personal computer (PC) and an Internet connection
can monitor and manage the director or switch through an embedded
web server interface.
embedded web
server interface
timeout
If the embedded web server interface is running but no user activity
occurs, (such as viewing different pages, refreshing, or reconfiguring
information), the application times out after 30 minutes. The user
must log in again. A login dialog box displays if the user attempts to
access any pages after the timeout has occurred.
embedded web
server interface
window
The window for the embedded web server interface. The window is
divided into two separate panels: the navigation panel on the left,
and the main panel on the right.
EMI See electromagnetic interference.
EMS application See EFC Management Services application.
enhanced availability
feature
EAF. A backup field-replaceable unit (backup FRU) that is ordered
and installed to provide redundancy and reduce disruption in case of
failure.
enterprise The entire storage system. The series of computers employed largely
in high-volume and multi-user environments such as servers or net-
working applications; may include single-user workstations required
in demanding design, engineering and audio/visual applications.
Enterprise Fabric
Connectivity
See EFC.
Enterprise Fabric
Connectivity Audit
Log
See EFC Audit Log.
Enterprise Fabric
Connectivity Event
Log
See EFC Event Log.
