General Information
Export Configuration Report
Select this option to display the Export Configuration Report dialog
box, which enables you to specify a file name in which to save an
ASCII text file containing all current user-definable configuration
options in a printable format. Note that this file cannot be read
back into the Element Manager in order to set configuration
parameters.
Enable Web Server
Select this option to place a check mark in the check box to enable
the EFCM Basic Edition interface on the switch. Select the option
again to remove the check mark and disable the EFCM Basic
Edition interface. When disabled, users at remote computers
running the client software cannot access the EFCM Basic Edition
interface.
Enable Telnet
Select this option to place a check mark in the check box to enable
telnet access to the switch. Select the option again to remove the
check mark and disable telnet access. When disabled, users at
remote workstations cannot access the switch through telnet to
use the Command Line Interface (CLI) or perform other tasks.
Logs Menu
Click the Logs menu to display the following options.
Audit Log
This log provides a record of all configuration changes made on
the switch. Each entry displays the date and time of the change, a
description of the change, the source of the change (such as the
Management Server or SNMP management station), and an
identifier for the source, such as the IP address of the
Management Server or SNMP management station.
Event Log
Select this option to display the switch event log. This log
provides a record of significant events that have occurred on the
switch, such as hardware failures, degraded operation, and port
problems. Each entry includes the date and time of the event, a
reason code for the event, the severity level, a brief description,
and up to 32 bytes of supplementary event data. For more
information, refer to Appendix B.
