Using the Element Manager
1-37
General Information
The parameters of the call home notification feature are
configured through your SAN management application. For
more information, refer to your SAN management application
Software User Manual.
NOTE: The Call Home Notification feature may be optional, depending
on your purchased software package.
Backup & Restore Configuration
Select this option to save the product configuration stored on the
switch to the Management Server hard disk or to restore the
configuration data from the Management Server. Only a single
copy of the configuration is kept on the server.
This backup is primarily for single-CTP systems, where a backup
is needed to restore the configuration data to a replacement CTP
card. You cannot modify the location or the file name of the saved
configuration.
NOTE: You can only restore the configuration to a switch with the same
IP address.
CAUTION
The following operation resets all configuration including any
optional features that have been installed. You will need to re-enter
your feature key to enable all optional features after resetting the
configuration.
Reset Configuration
Select this option to reset all switch configuration data back to the
factory defaults. A confirmation dialog box displays with a
warning upon selecting the option.
Help Menu
Click the Help menu to display the following options.
Contents
Select this option to display the Help window. The Help window
contains Contents, Index, and Glossary buttons and hypertext-
linked items to help you quickly navigate through information.
Use the forward (>) and back (<) buttons to scroll forward and
