McDATA® Sphereon 3032 and 3232 Fabric Switches Installation and Service Manual
Installation Tasks
Table 2-3 Defaults for Reset Configuration (Switch)
Table 2-2 Factory-Set Defaults (management server)
Item Default
Liquid crystal display (LCD) front panel 9999
Windows 2000 operating system user name (case sensitive) Administrator
Windows 2000 operating system password (case sensitive) password
SAN management application user name (case
sensitive)
Administrator
SAN management application password (case sensitive) password
LAN 1 (public interface) IP Address 192.168.0.1
Subnet mask 255.0.0.0
Gateway address 0.0.0.0
LAN 2 (private interface) IP Address 10.1.1.1
Subnet mask 255.0.0.0
Gateway address 0.0.0.0
Configuration Description Default
Identification Switch Name NULL string
Switch Description “Fibre Channel Switch”
Switch Contact “End User Contact (please configure)”
Switch Location “End User Contact (please configure)”
Ports Port Names NULL strings
Port Blocked States Unblocked
Extended Distance
(10-100km)
Disabled
LIN Alerts Disabled
Port Address Port number plus 4
Ports enabled 16
