Installation Tasks
Switch Addressing IP Address 10.1.1.10
Subnet Mask 255.0.0.0
Gateway Address 0.0.0.0
MAC Address PROM value
Switch Operating
Parameters
Preferred Domain
ID - Preferred
1
Preferred Domain
ID - Insistent
Disabled
Rerouting Delay Disabled
Domain RSCNs Disabled
Management Style Open Systems
Fabric Operating
Parameters
Buffer-to-Buffer
Credit
16
R_A_TOV 10 seconds (100 tenths)
E_D_TOV 2 seconds (20 tenths)
Switch Priority Default
Interop Mode McDATA Fabric 1.0
SNMP SNMP Communities “public” — 5 NULL strings
SNMP Write
Authorizations
Read only per community
Trap Recipient IP
Addressees
0 for each
UDP Port 162
SNMP Authorization
Tra p S ta t e
5
Management Server Active Equal Saved
State
Disabled
Remote Offline
Control State
Disabled
Configuration Description Default
