The Setup screen displays the following information:
• Change Network Settings
• Change Password
• Restore Factory Settings
• Lock Element Addressing (used on Cross Linked systems with 3 or more cabinets)
• Quick Loadport Open
• Drive Autoclean
• Drive Autounload
• Barcode Length
• Configured Drives
• Both Load Ports
• Left Load Port (##)
• Right Load Port (##)
Load port slot numbers will be different for each drive technology (Ultrium is 16 and 32, and
SDLT is 14 and 28).
6. To edit the setup information, use the Up and Down buttons to highlight the section and press
Select.
NOTE:
When Lock Element Addressing is enabled, the drive configuration and load port settings
cannot be changed from the Setup screen.
• To view or change network settings, highlight Change Network Settings and press Select.
• To set the IP address, subnet mask, and gateway, use the Up and Down buttons to select
the appropriate number and press Select to accept.
• To enable/disable DHCP, use the Up and Down buttons to toggle between enable/disable.
Press Select to accept the setting. If your library is not connected to a network that uses a
DHCP server to assign IP information, disable this function.
• To change the password, use the Up and Down buttons to select Change Password and press
Select. To change the password, enter a 6-digit password using the numbers provided on the
OCP. Press Select to accept the new password. When prompted, re-enter the password to
confirm.
• To enable Lock Element Addressing on a CLM library with 3 or more cabinets, use the Up
and Down buttons to select Lock Element Addressing, then press the Select button. Use the
Up and Down buttons to select Enabled or Disabled, then press the Select button.
• To enable faster opening of the load ports, use the Up and Down buttons to select Quick
Loadport Open, and then press Select. Use the Up and Down buttons to choose Enable or
Disable, and then press Select. The Open Ports button will appear which you can use to open
the load ports.
• To enable autoclean, use the Up and Down buttons to select Autoclean and press Select. The
default is disabled.
