Table 2 MSL2024, MSL4048, MSL8048, and MSL8096 Ultrium 1760 Tape Library specifications
SpecificationCharacteristic
LTO-4, half-heightTape drive
Native: 80 MB/s (288 GB/hr) Compressed (2:1): 160 MB/s
(576 GB/hr)
Maximum data transfer rate — one drive
Native: 160 MB/s (576 GB/hr) Compressed (2:1): 320 MB/s
(1152 GB/hr)
Maximum data transfer rate — two drives
Native: 240 MB/s (864 GB/hr) Compressed (2:1): 480 MB/s
(1728 GB/hr)
Maximum data transfer rate — three drives
Native: 320 MB/s (1152 GB/hr) Compressed (2:1): 640 MB/s
(2304 GB/hr)
Maximum data transfer rate — four drives
Table 3 MSL2024, MSL4048, MSL8048, and MSL8096 Ultrium 1840 Tape Library specifications
SpecificationCharacteristic
LTO-4, full-heightTape drive
Native: 120 MB/s (432 GB/hr) Compressed (2:1): 240 MB/s
(864 GB/hr)
Maximum data transfer rate — one drive
Native: 240 MB/s (864 GB/hr) Compressed (2:1): 480 MB/s
(1,728 GB/hr)
Maximum data transfer rate — two drives
Native: 360 MB/s (1,296 GB/hr) Compressed (2:1): 720 MB/s
(2,592 GB/hr)
Maximum data transfer rate — three drives
Native: 480 MB/s (1,728 GB/hr) Compressed (2:1): 960 MB/s
(3,456 GB/hr)
Maximum data transfer rate — four drives
Table 4 MSL2024, MSL4048, MSL8048, and MSL8096 Ultrium 3000 and 3280 Tape Library
specifications
SpecificationCharacteristic
LTO-5. Ultrium 3000 is half-height, Ultrium 3280 is full-heightTape drive
Native: 140 MB/s (504 GB/hr) Compressed (2:1): 280 MB/s
(1,004 GB/hr)
Maximum data transfer rate — one drive
Native: 280 MB/s (1,004 GB/hr) Compressed (2:1): 560 MB/s
(2,008 GB/hr)
Maximum data transfer rate — two drives
Native: 420 MB/s (1,512 GB/hr) Compressed (2:1): 840 MB/s
3,024 GB/hr)
Maximum data transfer rate — three drives
Native: 560 MB/s (2,008 GB/hr) Compressed (2:1): 1,120 MB/s
(4,016 GB/hr)
Maximum data transfer rate — four drives
Table 5 MSL2024, MSL4048, MSL8048, and MSL8096 Ultrium 6250 Tape Library specifications
SpecificationCharacteristic
LTO-6, half-heightTape drive
Native: 160 MB/s (576 GB/hr) Compressed (2.5:1): 400 MB/s
(1,440 GB/hr)
Maximum data transfer rate — one drive
Native: 320 MB/s (1,152 GB/hr) Compressed (2.5:1): 800 MB/s
(2,880 GB/hr)
Maximum data transfer rate — two drives
10 Features and overview
