NOTE: The number of drives available for selection in the Status menu depends on the number
of drives that have been active in the library. For a library that has only two drives, the menu
displays Drive 1 and Drive 2. For a library that has four drives, the menu displays Drive 1, Drive
2, Drive 3 and Drive 4 (even though the status of some may be offline or missing).
• Library: displays the status of the library without the drives. It shows the library status, odometer,
power on time, robotic status, slot and barcode of any cartridge in transport, number of free
and total slots, and status of the mailslots.
• Drives: displays the status of the selected drive. It shows the drive status, source slot, tape
barcode, error code (if appropriate), drive temperature, status of cooling fan, and drive activity.
For Fibre Channel drives, the following additional items are displayed:
◦ The link status of each port may be: No Light, Logged In, Logged Out, ALPA Conflict, or
Negotiation Link. No Light or ALPA Conflict indicates an error condition. See “Fibre
Channel connection problems” (page 147).
◦ The speed for each port: 1 Gb/s, 2 Gb/s, 4 Gb/s, or 8 Gb/s. Only speeds supported
by each port are displayed.
NOTE: Use the Left or Right buttons to toggle through the status information for all drives
without returning to the Info -> Status sub-menu.
Viewing identity information (Info > Identity Library)
Displays
• Library serial number
• Library product ID
• Controller and bootcode firmware revisions
• Library mode
• Number of reserved slots
• Status of the mailslot
• Library LUN Host Drive
A Fibre Channel library also displays the WW Node Name for the FC node to which it is connected.
World Wide names are assigned automatically; they cannot be configured.
Viewing identity information (Info > Identity Drives)
Displays the status of the selected drive. It shows the SCSI ID, physical drive number, serial number,
firmware revision, element address, the ID string, and whether the drive is the library LUN host
drive.
The following additional information is displayed for a Fibre Channel drive:
• WWide Node Name for the FC node to which the tape drive is connected.
• WWide Port Name and Port Type for Port A.
• WWide Port Name and Port Type for Port B.
NOTE: Use the Left or Right buttons to toggle through the identity information for all drives without
returning to the Info -> Identity menu.
World Wide names are assigned automatically; they cannot be configured.
MSL4048, MSL8048, and MSL8096 operator control panel 131
