Table 41 Main error codes (continued)
Details and solutionDescriptionError code
This error can occur is an attempt is made to
upgrade a drive with the wrong personality or
version for that drive.
Firmware upgrade errorD7
• Ensure that the correct drive firmware is being
used to update the drive.
• If the correct drive firmware is being used,
update the library firmware.
• Power cycle the device and attempt the
operation again.
Power-cycle the unit.Library controller data base errorD8
When running the wellness test, the bar code did
not match the previous value for that tape
DA
• Check the bar code label for proper
application and damage.
• Run the wellness test again.
I2C Bus failure.DC
• Power-cycle the device.
• On the MSL4048, MSL8048, and MSL8096,
power off the library and re-seat the library
controller from the back panel.
Incompatible magazine detected. The mailslot
was enabled with a different mailslot magazine
E0
• Either replace the lower left magazine with
the original magazine, or disable and
type than is currently in the library. For example,
re-enable the mailslot to reconfigure the library
the mailslot was enabled with a three-slot mailslot
176 Troubleshooting
