Table 50 Warning event codes (continued)
Details and SolutionDescriptionEvent code
Parity error58
• Retry the operation.
Error log overflow59
• If the problem continues, contact HP customer
support.
Disable encryption before downgrading firmware.Unable to downgrade firmware while encryption
enabled.
5A
Invalid cartridge. LTO3 media is not supported
with encryption enabled.
5B
• Verify that the tape cartridge is supported.
• Update the tape drive firmware to the latest
version to use LTO3 media.
Change the network settings to IPv4 before
downgrading firmware.
IPv6 will not be supported after downgrading
firmware.
5C
Drive firmware is specific to the drive model and
interface. Select the drive firmware specific to this
Wrong drive firmware — invalid drive firmware
type.
5D
drive. If the firmware file could have been
renamed, obtain a new copy of the firmware file
In an MSL4048, a full-height tape drive may not
be installed in the middle two drive bays; it must
Illegal drive position of FH drive.5E
be installed in either the upper two drive bays or
lower two drive bays. Reinstall the tape drive in a
supported drive bay.
The device firmware may not be downgraded in
cases that would compromise encrypted data,
No firmware downgrade possible.5F
critical component support, or license terms. Check
the configuration settings. If the device has been
using the Encryption Kit, you may need to disable
encryption before downgrading firmware. If the
Library Extender is installed, you may need to
uninstall the Library Extender before downgrading
firmware.
Complete the cleaning process and retry the
operation.
Cleaning tape installed.60
Cleaning failure. Cleaning process could not be
performed.
61
• Check cleaning tape and exchange if
necessary.
• Retry the operation.
Exchange the cleaning tape.Cleaning tape expired.62
Invalid cartridge. Drive has rejected the cartridge
as invalid.
63
• Verify that the cartridge generation and
technology are supported by the device. See
“Tape cartridges” (page 57).
Invalid cleaning cartridge. Drive has rejected the
cartridge as invalid.
64
• Retry the operation.
• If problems persist, exchange the data
cartridge.
Invalid upgrade cartridge. Drive has rejected the
cartridge as invalid.
65
• Retry the operation.
• If problems persist, exchange the data
cartridge.
The diagnostic test needs to write data but the tape
being used for the test is write protected. Ensure
Diagnostic tape write protect.66
that the device has a tape that is not write
protected for use during the diagnostic test.
The drive tried to read or write data from a tape
from an incompatible LTO generation. For
Incompatible medium67
Warning events 191
