Table 51 Configuration change events (continued)
DescriptionConfiguration eventValue
Drive was enabledDrive enable0x43
Drive disabledDrive disable0x44
Drive master assignedMaster drive assigned0x45
Drive sled addedDrive sled added0x46
Drive sled removedDrive sled removed0x47
Library mode changed (automatic, sequential,
random)
Library mode changed0x48
Element address changedElement address0x49
Network parameter has changedNet parameter0x4A
Slots reservedSlots reserved0x4B
Mailslot supportMailslot support0x4C
Admin password has changedAdmin password0x4D
Date and time of RTC setDate/time set0x4E
Barcode format alignment changedBarcode format0x4F
Default configuration setDefault config set0x50
Library firmware was upgradedFW upgrade library0x51
Drive firmware was upgradedFW upgrade drive0x52
Auto-cleaning switched on or offAuto-clean feature set0x53
Drive Fibre Channel parameters changedDrive FC parameters0x54
A power supply was added to the systemPower supply added0x55
A key server token was removedKey server token was removed0x56
A key server token was insertedKey server token was inserted0x57
Encryption has been enabledEncryption has been enabled0x58
Encryption has been disabledEncryption has been disabled0x59
The library extender has been insertedExtender unit has been inserted0x60
The library extender has been removedExtender unit has been removed0x61
The library extender has been enabledExtender unit has been enabled0x62
The library extender has been disabledExtender unit has been disabled0x63
The status of the library door lock has changedLibrary door lock status change0x64
Hostname has been changedHostname has been changed0x65
The library configuration has been restored from
the robot
Database has been restored from robot0x66
The serial number has been changedSerial number has been changed0x67
The world wide identifier base has been changedWorld wide identifier base has been changed0x68
EUI64 identifier has been changedEUI64 identifier has been changed0x69
License key has been added or removedLicense key has been added or removed0x6E
User interface language has changedUser interface language change0x6F
Configuration change events 195
