A Technical specifications
Physical specifications
Table 55 MSL2024 tape library physical specifications: all models
PackagedProduct aloneCharacteristics
250 mm (9.84 inches)87.5 mm (3.44 inches)Height
580 mm (22.83 inches)445 mm (17.5 inches)Width
990 mm (38.97 inches)775.5 mm (30.53 inches)Depth
25.5 (56.22 pounds)15 kg (33.07 pounds)Weight
Table 56 MSL4048 tape library physical specifications: all models
PackagedProduct aloneCharacteristics
344 mm (13.54 inches)174 mm (6.85 inches)Height
596 mm (23.46 inches)445 mm (17.5 inches)Width
994 mm (39.13 inches)776 mm (30.55 inches)Depth
33.2 (73.04 pounds)20.6 kg (45.32 pounds)Weight
Table 57 MSL8048 and MSL8096 Tape Library physical specifications: all models
PackagedProduct aloneCharacteristics
533 mm (20.98 inches)352 mm (13.86 inches)Height
589 mm (23.19 inches)480 mm (18.9 inches)Width
987 mm (38.86 inches)806 mm (31.73 inches)Depth
66.6 (146.8 pounds)46.6 kg (102.7 pounds)Weight
Environmental specifications
Table 58 Environmental specifications
SpecificationCharacteristic
Temperature
10º to 35º COperating
-30º to 60º CNon-operating
10º to 35º CRecommended operating temperature
10º C per hourTemperature shock immunity - maximum rate of change
Miscellaneous
less than 200 microgram/cubic meterDust concentration
3050 meters (10,000 ft.)Altitude
Humidity
20% to 80% RH non-condensingOperating
20% to 80% RH non-condensingNon-operating
