• Error recovery: On
• Mailslot configuration: mailslot disabled
• Auto clean: disabled
• SNMP: disabled, but saved addresses do not change
• E-mail notification: disabled, but configurations retained
The following settings are not reset:
• Administrator password
• Network settings (network is always enabled and the network addresses are retained)
• Date and time
IMPORTANT: When the defaults are restored, the library will rediscover and renumber the tape
drives from the bottom of the library up. If a tape drive was added between two other tape drives
since the last time the drives were discovered, that tape drive and the ones above it will be
renumbered. You might need to update the configuration of the backup application when tape
drives are renumbered.
Setting the library date and time (Configuration > Set Date and Time)
This option sets the date and time used by the library to record events. Access to this feature requires
the administrator password.
NOTE: Time is based on a 24-hour clock. There is no a.m. or p.m. designation. For example:
1:00 p.m. is 13:00.
Saving and restoring the library configuration (Configuration> Save/Restore)
This option saves the library configuration to a USB flash drive and restores the configuration from
the USB flash drive.
The configuration settings that are saved are:
• Administrator password
• Mailslot configuration
• All network settings, including DHCP, DNS, IPv4 and IPv6 addresses
• Barcode reader label length and barcode reader alignment
• Reserved slots
• Display contrast setting
• Library mode
• All drive configuration settings
• Auto clean
• SNMP addresses and configurations
• Log tracing configuration
• Email notification configuration (SMTP address, email address, filter level)
• Option to allow the magazine access without the administrator password
• Option to ignore the barcode media ID
• Logical library configuration
• Encryption and security settings
