Table 48 Sub error codes related to robotics errors during movement to extender position (continued)
MessageSub-code
Error during third slider movement (move to block) from/to extender positionFD
Error during third gripper movement (close gripper) from extender positionFE
Error during fourth slider movement (pull back) from/to extender positionFF
Drive error codes
Table 49 Drive error codes
DescriptionError code
Drive broken01
Temperature exceeds limit02
Tape error03
Cleaning cartridge is expired04
Drive needs cleaning05
Library lost communication with the drive06
Warning that the tape is nearing its end of life07
188 Troubleshooting
