Warning events
Table 50 Warning event codes
Details and SolutionDescriptionEvent code
The application software made an illegal request.
SCSI: transport element full30
SCSI: all slots empty31
SCSI: invalid opcode32
SCSI: invalid element address33
SCSI: invalid field in CDB34
SCSI: invalid drive specified35
SCSI: SEND DIAGNOSTIC command: invalid
test number
36
SCSI: invalid LUN37
SCSI: parameter list length error38
SCSI: parameter list error: invalid field39
SCSI: parameter list error: parameter not
supported
3A
The application software made an illegal request.
SCSI: parameter value invalid3B
SCSI: saving parameters not supported3C
SCSI: invalid ID message3D
SCSI: destination element full3E
SCSI: source slot or drive empty3F
SCSI: wrong checksum40
SCSI: command sequence error41
The application software requested to use a drive
that is disabled. Check the device configuration.
SCSI: drive disabled42
The application software requested to use the
mailslot, but the mailslot is disabled. Check the
device configuration.
SCSI: mailslot disabled43
Check the version of firmware used for the
upgrade. The firmware is incompatible with this
device.
SCSI: flash image does not fit bootcode44
The application software has locked media
removal and either the software or device user
interface attempted to remove the media.
SCSI: media removal prevented by drive45
SCSI: media removal prevented by library46
NOTE: This IS NOT a hardware issue.
If the issue cannot be resolved with the application
software, power off the device, disconnect the data
cable, and then power on the device.
Check the firmware file used for the upgrade. The
firmware is incompatible with this device.
SCSI: flash image does not fit personality47
The tape drive is not supported by the firmware in
this device. Upgrade the device firmware to the
SCSI: tape drive not supported by this library48
most up-to-date version. Verify that the drive has
an HP MSL-G3 or 1/8 G2 firmware revision. If
firmware is not the correct type, the wrong tape
Warning events 189
