Table 50 Warning event codes (continued)
Details and SolutionDescriptionEvent code
Replace the drive with a compatible tape drive.Drive not supported; the tape drive was disabled
because it cannot be used in this library.
87
Drive firmware revision has not changed after a
tape drive firmware upgrade.
88
• Verify that the firmware image is correct for the
tape drive.
• Retry the operation.
• Retry using an alternate firmware upgrade
method.
Power supply fan has failed. Redundancy may
be at risk.
89
• Verify that the indicated fan is operational and
not physically obstructed.
• Upgrade to the latest version of firmware.
NOTE: The sub-error code indicates the affected
power supply. 00 is the bottom power supply. 01
is the second power supply.
Power supply has failed. Redundancy is not
available.
8A
• Check the AC power cable connection.
• Verify that the indicated power supply is
correctly installed and the thumbscrews are
tight.
NOTE: The sub-error code indicates the affected
power supply. 00 is the bottom power supply. 01
is the second power supply.
One of the redundant power supplies has failed.8B
• Check the AC power cable connections.
• Verify that both power supplies are correctly
installed and the thumbscrews are tight.
Install new library firmware, which will install a
compatible robotics firmware version.
Invalid robotics code; does not match with the
loaded library firmware.
8C
Obtain a new cleaning tape for use when the
current cleaning tape expires.
Cleaning tape nearly expired. Only one or two
cleaning operations remain.
8E
Contact HP Service if this unexpected condition
occurs.
I
2
C bus recovery8F
Power supply has failed. Master library power
redundancy not available.
90
• Verify that both power supplies are correctly
installed and the thumbscrews are tight.
Power supply has failed. Lower library power
redundancy not available.
91
• Check AC power cable connections
NOTE: The MSL2024 does not have a redundant
power supply option.
Power cycle the device and retry the operation.VPD data recovery.92
Verify that the fan for the indicated drive sled is
operational and not obstructed.
External drive cooling fan failure (fan motion has
stopped). The subcode indicates which drive sled
fan is affected.
DB
NOTE: The fan only operates when cooling is
required.
Subcode 00: drive sled #1
Subcode 01: drive sled #2
etc.
Warning events 193
